Page through all channel data and alarms in a quick view mode or scroll through channels and channel statistics individually. View your data with the push of a button. Top-of-screen menu bar headings always let you know where you are in the setup process. You always have visible confirmation when your data is being recorded.Ĭopy-and-paste channel functions make repetitive channel setups a simple task. The "Record" key illuminates to indicate when the 2638A is recording data in scan, monitor or DMM mode.
HYDRA PEAK FULL
The large, full color, thin film diode (TFD) display enables the Hydra Series III to display comprehensive easy-to-understand data and easy menu navigation.īack-lighted function keys quickly confirm the active menu selection. Never get lost again in a complex menu tree while configuring channels or setting up a test. Graphical color display with easy-to-use menus When you need data from that site, simply "plug in" and load your saved setup file. Using multiple low-cost Universal Input Connectors gives you the flexibility to leave your input connector at the test site, completely wired, and ready to use. With Hydra Series III, all your signal conditioning is inside the mainframe, not in your input connector. If you need your instrument for another test at another location, you must remove your wiring or use another expensive plug-in signal conditioning module. Other data loggers require you to wire your inputs directly to an expensive "plug-in" active component signal conditioning module. With the inexpensive plug-in Universal Input Connector, you can wire your system once, quickly disconnect the connector from your Hydra, then reconnect the Hydra to another input connector for use in a different area. Wiring a test or system setup for 20 or more channels can be time consuming. This feature is a valuable form of traceability if you are working in a regulated industry. This information is saved in the test setup data file, which is available for review with any associated scan data from a test setup.
HYDRA PEAK SERIAL NUMBER
The calibration date and input connector serial number are programed into the input connector and are read by the 2638A/05 when installed. Each input connector contains a CJC (cold-junction compensation) device, which is calibrated at the factory. The Universal Input Connector has 22 input channels (20 universal inputs and 2 dedicated, low-burden input current channels). The Universal Input Connector plugs into the slot in the 2638A/05 that contains a serviceable relay card. If you are conducting chamber tests, heat treating tests under AMS guidelines, or validating temperature devices under 21 CFR regulations, Hydra Series III makes it that much easier to comply. If you need to "zero" a large number of thermocouples to a known reference temperature before starting a temperature profiling or validation test, the 2638A/05 will normalize all readings to your reference channel at the push of a button and store the offsets for reference in a supporting data file. Temperature-focused menu selections make the 2638A/05 especially suitable for temperature validation applications. The Universal Input Connector supports 14 common thermocouple types. The 2638A/05 incorporates the Fluke patented Universal Input Connector to bring more accuracy to thermocouple measurements than most other instruments in its class.
HYDRA PEAK SOFTWARE
You can also use the 2638A/05 with optional software and other Fluke data loggers to create a flexible, customized data acquisition system.Īccurate industrial thermocouple measurements Selectable inputs include dc voltage, ac voltage, resistance, thermocouple, RTD, thermistor, frequency and dc and ac current. The 2638A/05 is a 22 channel true differential analog input data logger with the Fluke Universal Input Connector that lets you connect and disconnect any type of input to any channel, quickly and easily. The dedicated 6.5 digit digital multimeter (DMM) mode provides additional utility and value.
HYDRA PEAK PORTABLE
The Series III improves on Hydra’s industry leading thermocouple accuracy and adds a new dimension to how you collect and view data in a portable system.ĭC measurement accuracy of 0.0024 %, basic 0.5 ☌ thermocouple accuracy, full-color display, easy-to-use menu system and industrial safety ratings put the 2638A in a category of its own as a precision data acquisition system.
The Fluke 2638A/05 Hydra Series III continues the Hydra Series legacy of precision, multi-channel data acquisition. Price-performance breakthrough in a stand-alone data acquisition system
